Leica Disto x4 150m range- Outdoor Laser Distance Meter
Typ. distance measuring accuracy ± 1.0 mm / 0.04 in
Range 0.05 up to 150m / 0.16 up to 495 ft
Measuring unitsm, ft, in
X-Range Power Technology yes
Distance in mØ of the laser dot in mm10, 50, 100 m6, 30, 60 mm
Tilt sensor yes
Tilt sensor accuracy to the laser beam ± 0.2°
Tilt sensor accuracy to the housing ± 0.2°Units in the tilt sensor 0.0°, 0.00 %
Measuring range with DST 360 Horizontal Vertical 360°−64° to > 90°Distance in m
Typ. tolerance of the P2P function with DST 3602, 5, 10 m± 2, 5, 10 mm
Levelling range with DST 360± 5°
Pointfinder with zoom 4 x
Memory for last measurements 20
Display illumination yes
Free software for Windows yes
Free App for iOS and Android yes
Smart Room support yes
General data interface Bluetooth®
SmartData interface for 3D point data with DST 360 Bluetooth® Smart
SmartData interface for 3D point data with DST 360 Bluetooth® SmartMeasurements per set of batteries up to 4,000*
Service life of batteriesup to 8 h*
Multifunctional endpiece yes
Automatic reference detection for endpiece yes
Tripod thread 1/4"
Batteriestype AA 2 x 1.5 V
Protection class IP65
2 m drop tested "applies to the DISTO device" yes
Dimensions 132 × 56 × 29 mm / 5.20 x 2.20 x 1.14 in (H x D x W)
Weight with batteries 188 g / 0.41 lbs
*Reduced when used with Bluetooth® or Leica DST 360
or Leica DST 360 X4 in water
Also compatible with the DST 360.
The DST 360 is a smart tripod and adapter set that extends the measurement possibilities of your X4. With the DST 360, your X4 turns into a professional measurement station—you can take point to point (P2P) measurements from one location.
Capable of Point-to-Point (P2P) measurement technology.
When used with the DST 360, the X4 can combine rotation, angle, and distance data to produce highly accurate Point-to Point (P2P) measurements, which allows you to accurately measure distances between any two points from a third position.
Mobile device connectivity for the DISTO Plan App.
Use the DISTO Plan App to access Sketch, Document, and Smart Room features to create detailed CAD-ready floor and wall plans, including doors and windows. Export your plans as .DXF or .DWG files. Want to learn more?
DISTO Technology Overview
Point to Point (P2P) Technology Overview
Improving LDM performance outdoors – How can I see the laser spot better?
